Custom leaf spring enquiries from your drawing
A leaf or beam-type spring deflects under load between its supports or attachments. Its function depends on the loading direction, support arrangement and permitted movement, not only on its outline.
Bring us the drawing or sample and the installation details. We will assess the dimensions, material, loading and forming requirements together before confirming the manufacturing scope.
Define loading, supports and working movement
- A dimensioned drawing or clear sample photographs, including thickness, width and free shape.
- Support and attachment locations, mating parts and the direction of loading.
- Required load at defined deflections, with units and acceptance limits.
- Installed and maximum working positions, clearances and mechanical stops.
- Material requirement, operating environment and target duty.
- Sample quantity, production quantity and intended schedule.
Specify the thickness, width, free shape and working load on your drawing. We confirm the usable material and dimensions for this part; the strip ranges shown on our other product pages are not the specification for industrial leaf springs.
Start with a drawing or sample
We can review PDF, DWG, DXF and STEP drawings. If you have a sample, include photographs, support positions, installation space and the load needed at each working deflection. These details let us assess the part and the tooling it would require.
If the part primarily retains or locates another component, the spring clips and flat forms category may be the clearer starting point. Describe the mechanism if the product name is uncertain.
Questions before requesting a quote
What do you need to confirm the manufacturing scope?
Please send the dimensioned drawing, material requirement, support arrangement and load at the working deflection. A photograph is useful for orientation, but those details are needed before we can confirm that the part fits our manufacturing scope.
Which materials, MOQ and timing are available?
Send the drawing, operating conditions, sample quantity and production quantity. We will confirm the material, tooling, minimum order and schedule after assessing the specific part.
Discuss your spring requirements
Send your drawing or sample information with the loading, mounting and quantity requirements.
